B43505A9157M000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 150UF 20% 400V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet B43505A9157M000 Datasheet
-
ECAD Model
- Share
In Stock: 660
Can ship immediately
Pricing:
- 1$5.76
- 10$5.18085
- 100$3.91418
- 500$3.2234
- 1,000$2.99315
- 2,500$2.9356
Quote It
Technical Details
- Series:B43505
- Package:Bulk
- Part Status:Not For New Designs
- Capacitance:150 µF
- Tolerance:±20%
- Voltage - Rated:400 V
- ESR (Equivalent Series Resistance):590mOhm @ 100Hz
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:950 mA @ 100 Hz
- Ripple Current @ High Frequency:-
- Impedance:730 mOhms
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:0.984" Dia (25.00mm)
- Height - Seated (Max):1.654" (42.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
