LAQ2P561MELB35
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 560UF 20% 220V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet LAQ2P561MELB35 Datasheet
-
ECAD Model
- Share
In Stock: 339
Can ship immediately
Pricing:
- 1$5.92
- 10$5.26264
- 100$4.21039
- 500$3.61832
- 1,000$3.57885
Quote It
Technical Details
- Series:LAQ
- Package:Bulk
- Part Status:Active
- Capacitance:560 µF
- Tolerance:±20%
- Voltage - Rated:220 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-25°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.6 A @ 120 Hz
- Ripple Current @ High Frequency:1.92 A @ 10 kHz
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:1.181" Dia (30.00mm)
- Height - Seated (Max):1.457" (37.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
