B43642C5277M000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 270UF 20% 450V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet B43642C5277M000 Datasheet
-
ECAD Model
- Share
In Stock: 354
Can ship immediately
Pricing:
- 1$6.09
- 10$5.41012
- 100$4.32791
- 500$3.71934
- 1,000$3.67875
Quote It
Technical Details
- Series:B43642
- Package:Bulk
- Part Status:Active
- Capacitance:270 µF
- Tolerance:±20%
- Voltage - Rated:450 V
- ESR (Equivalent Series Resistance):310mOhm @ 100Hz
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.63 A @ 100 Hz
- Ripple Current @ High Frequency:-
- Impedance:440 mOhms
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:1.378" Dia (35.00mm)
- Height - Seated (Max):1.260" (32.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
