B43634A2687M060
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 680UF 20% 200V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet B43634A2687M060 Datasheet
-
ECAD Model
- Share
In Stock: 797
Can ship immediately
Pricing:
- 1$6.32
- 10$5.61985
- 100$4.4957
- 500$3.86353
- 1,000$3.82137
Quote It
Technical Details
- Series:B43634
- Package:Bulk
- Part Status:Active
- Capacitance:680 µF
- Tolerance:±20%
- Voltage - Rated:200 V
- ESR (Equivalent Series Resistance):140mOhm @ 100Hz
- Lifetime @ Temp.:8000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:2.57 A @ 100 Hz
- Ripple Current @ High Frequency:-
- Impedance:200 mOhms
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:0.866" Dia (22.00mm)
- Height - Seated (Max):1.654" (42.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
