B43508A5337M000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 330UF 20% 450V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet B43508A5337M000 Datasheet
-
ECAD Model
- Share
In Stock: 731
Can ship immediately
Pricing:
- 1$9.31
- 10$8.27545
- 100$6.62064
- 500$5.68962
- 1,000$5.62756
Quote It
Technical Details
- Series:B43508
- Package:Bulk
- Part Status:Active
- Capacitance:330 µF
- Tolerance:±20%
- Voltage - Rated:450 V
- ESR (Equivalent Series Resistance):370mOhm @ 100Hz
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.47 A @ 100 Hz
- Ripple Current @ High Frequency:-
- Impedance:530 mOhms
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:0.984" Dia (25.00mm)
- Height - Seated (Max):2.244" (57.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
