B43644A5477M000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 470UF 20% 450V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet B43644A5477M000 Datasheet
-
ECAD Model
- Share
In Stock: 325
Can ship immediately
Pricing:
- 1$10.86
- 10$9.65123
- 100$7.72067
- 500$6.63495
- 1,000$6.56256
Quote It
Technical Details
- Series:B43644
- Package:Bulk
- Part Status:Not For New Designs
- Capacitance:470 µF
- Tolerance:±20%
- Voltage - Rated:450 V
- ESR (Equivalent Series Resistance):220mOhm @ 100Hz
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:2.26 A @ 100 Hz
- Ripple Current @ High Frequency:-
- Impedance:330 mOhms
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:1.181" Dia (30.00mm)
- Height - Seated (Max):2.244" (57.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
