EEV-FK1K100P
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 10UF 20% 80V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEV-FK1K100P Datasheet
-
ECAD Model
- Share
In Stock: 63,916
Can ship immediately
Pricing:
- 1$0.64
- 1,000$0.15245
Quote It
Technical Details
- Series:FK
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Capacitance:10 µF
- Tolerance:±20%
- Voltage - Rated:80 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:-
- Ripple Current @ High Frequency:60 mA @ 100 kHz
- Impedance:2.4 Ohms
- Lead Spacing:-
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.256" (6.50mm)
- Surface Mount Land Size:0.327" L x 0.327" W (8.30mm x 8.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
