860020773013
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 47UF 20% 63V RADIAL
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 1,548
Can ship immediately
Pricing:
- 1$0.18
- 1,500$0.10639
Quote It
Technical Details
- Series:WCAP-ATG5
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:47 µF
- Tolerance:±20%
- Voltage - Rated:63 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:125 mA @ 120 Hz
- Ripple Current @ High Frequency:191.25 mA @ 100 kHz
- Impedance:-
- Lead Spacing:0.098" (2.50mm)
- Size / Dimension:0.248" Dia (6.30mm)
- Height - Seated (Max):0.492" (12.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
