860010674014
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP 100 UF 20% 50 V
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 1,472
Can ship immediately
Pricing:
- 1$0.26
- 800$0.16175
- 1,600$0.15375
Quote It
Technical Details
- Series:WCAP-ATG8
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:100 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:286 mA @ 120 Hz
- Ripple Current @ High Frequency:437.58 mA @ 100 kHz
- Impedance:-
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.512" (13.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
