UPW1A220MDD6TP
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 22UF 20% 10V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPW1A220MDD6TP Datasheet
-
ECAD Model
- Share
In Stock: 2,055
Can ship immediately
Pricing:
- 1$0.29
- 2,000$0.06101
- 4,000$0.05643
- 10,000$0.05338
- 14,000$0.05063
- 50,000$0.04576
- 100,000$0.04042
Quote It
Technical Details
- Series:UPW
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:22 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:19.5 mA @ 120 Hz
- Ripple Current @ High Frequency:120 mA @ 100 kHz
- Impedance:2 Ohms
- Lead Spacing:0.059" (1.50mm)
- Size / Dimension:0.157" Dia (4.00mm)
- Height - Seated (Max):0.315" (8.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
