ECA-1EHG101B
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 100UF 20% 25V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet ECA-1EHG101B Datasheet
-
ECAD Model
- Share
In Stock: 2,148
Can ship immediately
Pricing:
- 1$0.33
- 2,000$0.07425
- 4,000$0.07013
- 10,000$0.066
- 14,000$0.06394
- 50,000$0.05775
- 100,000$0.0561
Quote It
Technical Details
- Series:NHG
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:100 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:130 mA @ 120 Hz
- Ripple Current @ High Frequency:195 mA @ 100 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.248" Dia (6.30mm)
- Height - Seated (Max):0.480" (12.20mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
