EEU-FR1C680B
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 68UF 20% 16V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-FR1C680B Datasheet
-
ECAD Model
- Share
In Stock: 1,325
Can ship immediately
Pricing:
- 1$0.35
- 2,000$0.07247
- 4,000$0.06704
- 10,000$0.06341
- 14,000$0.06015
- 50,000$0.05435
- 100,000$0.04801
Quote It
Technical Details
- Series:FR
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:68 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:196 mA @ 120 Hz
- Ripple Current @ High Frequency:280 mA @ 100 kHz
- Impedance:300 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.197" Dia (5.00mm)
- Height - Seated (Max):0.492" (12.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
