EEU-FR1A271B
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 270UF 20% 10V RADIAL TH
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 1,814
Can ship immediately
Pricing:
- 1$0.36
- 200$0.13577
- 400$0.11314
- 600$0.10183
- 1,000$0.08599
- 2,000$0.08146
- 5,000$0.07694
- 10,000$0.07241
- 20,000$0.07015
Quote It
Technical Details
- Series:FR
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:270 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:318.5 mA @ 120 Hz
- Ripple Current @ High Frequency:455 mA @ 100 kHz
- Impedance:130 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.248" Dia (6.30mm)
- Height - Seated (Max):0.500" (12.70mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
