ULT2E8R2MNL1GS
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 8.2UF 20% 250V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet ULT2E8R2MNL1GS Datasheet
-
ECAD Model
- Share
In Stock: 1,501
Can ship immediately
Pricing:
- 1$0.89
- 500$0.33818
- 1,000$0.28478
- 2,500$0.26698
- 5,000$0.24919
- 12,500$0.23673
- 25,000$0.23139
Quote It
Technical Details
- Series:ULT
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:8.2 µF
- Tolerance:±20%
- Voltage - Rated:250 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 125°C
- Operating Temperature:-40°C ~ 125°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:30 mA @ 120 Hz
- Ripple Current @ High Frequency:45 mA @ 10 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.433" (11.00mm)
- Surface Mount Land Size:0.327" L x 0.327" W (8.30mm x 8.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
