UCZ1H220MCS1GS
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 22UF 20% 50V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UCZ1H220MCS1GS Datasheet
-
ECAD Model
- Share
In Stock: 1,519
Can ship immediately
Pricing:
- 1$0.92
- 900$0.32378
- 1,800$0.30415
- 2,700$0.28454
- 4,500$0.26982
- 9,000$0.26687
Quote It
Technical Details
- Series:UCZ
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:22 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):500mOhm @ 100kHz
- Lifetime @ Temp.:2000 Hrs @ 125°C
- Operating Temperature:-40°C ~ 125°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:98.5 mA @ 120 Hz
- Ripple Current @ High Frequency:197 mA @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.248" Dia (6.30mm)
- Height - Seated (Max):0.315" (8.00mm)
- Surface Mount Land Size:0.260" L x 0.260" W (6.60mm x 6.60mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
