EEU-FC1A471
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 470UF 20% 10V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-FC1A471 Datasheet
-
ECAD Model
- Share
In Stock: 630
Can ship immediately
Pricing:
- 1$0.49
- 10$0.343
- 100$0.20545
- 500$0.15409
- 1,000$0.13012
- 2,500$0.12327
- 5,000$0.11642
Quote It
Technical Details
- Series:FC
- Package:Bulk
- Part Status:Active
- Capacitance:470 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:416.25 mA @ 120 Hz
- Ripple Current @ High Frequency:555 mA @ 100 kHz
- Impedance:117 mOhms
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.453" (11.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
