EKYB250ELL151MF11D
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 150UF 20% 25V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EKYB250ELL151MF11D Datasheet
-
ECAD Model
- Share
In Stock: 608
Can ship immediately
Pricing:
- 1$0.52
- 10$0.3575
- 100$0.21499
- 500$0.1612
- 1,000$0.13613
- 2,500$0.12896
- 5,000$0.12179
Quote It
Technical Details
- Series:KYB
- Package:Bulk
- Part Status:Active
- Capacitance:150 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:7000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:216 mA @ 120 Hz
- Ripple Current @ High Frequency:540 mA @ 100 kHz
- Impedance:150 mOhms
- Lead Spacing:0.098" (2.50mm)
- Size / Dimension:0.248" Dia (6.30mm)
- Height - Seated (Max):0.492" (12.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
