UKT1V221MPD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 220UF 20% 35V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UKT1V221MPD Datasheet
-
ECAD Model
- Share
In Stock: 561
Can ship immediately
Pricing:
- 1$0.63
- 10$0.4452
- 100$0.29285
- 500$0.21693
- 1,000$0.18439
- 2,500$0.17354
- 5,000$0.1627
Quote It
Technical Details
- Series:UKT
- Package:Bulk
- Part Status:Active
- Capacitance:220 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:Audio
- Ripple Current @ Low Frequency:260 mA @ 120 Hz
- Ripple Current @ High Frequency:390 mA @ 10 kHz
- Impedance:-
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.453" (11.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
