UPW1A122MPD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1200UF 20% 10V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPW1A122MPD Datasheet
-
ECAD Model
- Share
In Stock: 853
Can ship immediately
Pricing:
- 1$0.78
- 10$0.54852
- 100$0.36094
- 500$0.26736
- 1,000$0.22725
- 2,500$0.2139
- 5,000$0.20052
Quote It
Technical Details
- Series:UPW
- Package:Bulk
- Part Status:Active
- Capacitance:1200 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.037 A @ 120 Hz
- Ripple Current @ High Frequency:1.22 A @ 100 kHz
- Impedance:52 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.787" (20.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
