UPJ1J561MHD6TN
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 560UF 20% 63V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPJ1J561MHD6TN Datasheet
-
ECAD Model
- Share
In Stock: 550
Can ship immediately
Pricing:
- 1$1.8
- 250$0.86128
- 500$0.7321
- 750$0.68902
- 1,250$0.64596
- 2,500$0.6029
- 6,250$0.58567
Quote It
Technical Details
- Series:UPJ
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:560 µF
- Tolerance:±20%
- Voltage - Rated:63 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.4 A @ 120 Hz
- Ripple Current @ High Frequency:1.73 A @ 10 kHz
- Impedance:58 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.709" Dia (18.00mm)
- Height - Seated (Max):0.846" (21.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
