UPW1A332MHD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 3300UF 20% 10V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPW1A332MHD Datasheet
-
ECAD Model
- Share
In Stock: 793
Can ship immediately
Pricing:
- 1$1.1
- 10$0.86854
- 100$0.65095
- 500$0.49186
- 1,000$0.43398
- 2,500$0.40505
- 5,000$0.39059
Quote It
Technical Details
- Series:UPW
- Package:Bulk
- Part Status:Active
- Capacitance:3300 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:7000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.658 A @ 120 Hz
- Ripple Current @ High Frequency:1.95 A @ 100 kHz
- Impedance:30 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):0.984" (25.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
