UPW1V152MHD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1500UF 20% 35V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPW1V152MHD Datasheet
-
ECAD Model
- Share
In Stock: 1,032
Can ship immediately
Pricing:
- 1$1.18
- 10$0.93112
- 100$0.69824
- 500$0.52752
- 1,000$0.46546
- 2,500$0.43443
- 5,000$0.42202
Quote It
Technical Details
- Series:UPW
- Package:Bulk
- Part Status:Active
- Capacitance:1500 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:8000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:-
- Ripple Current @ High Frequency:2.555 A @ 100 kHz
- Impedance:22 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.984" (25.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
