UCA2W220MHD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 22UF 20% 450V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UCA2W220MHD Datasheet
-
ECAD Model
- Share
In Stock: 990
Can ship immediately
Pricing:
- 1$1.74
- 10$1.37702
- 100$1.03293
- 500$0.78044
- 1,000$0.68862
- 2,500$0.64272
- 5,000$0.62435
Quote It
Technical Details
- Series:UCA
- Package:Bulk
- Part Status:Active
- Capacitance:22 µF
- Tolerance:±20%
- Voltage - Rated:450 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:12000 Hrs @ 105°C
- Operating Temperature:-25°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:280 mA @ 120 Hz
- Ripple Current @ High Frequency:560 mA @ 100 kHz
- Impedance:-
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):1.043" (26.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
