UBT1H471MHD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP 470UF 50V RAD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UBT1H471MHD Datasheet
-
ECAD Model
- Share
In Stock: 735
Can ship immediately
Pricing:
- 1$1.84
- 10$1.4536
- 100$1.08986
- 500$0.82344
- 1,000$0.72657
- 2,500$0.67813
- 5,000$0.65875
Quote It
Technical Details
- Series:UBT
- Package:Bulk
- Part Status:Active
- Capacitance:470 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 125°C
- Operating Temperature:-40°C ~ 125°C
- Polarization:Polar
- Ratings:-
- Applications:Automotive
- Ripple Current @ Low Frequency:825 mA @ 120 Hz
- Ripple Current @ High Frequency:1.65 A @ 100 kHz
- Impedance:55 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):1.063" (27.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
