EEE-TP1K391V
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 390UF 20% 80V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEE-TP1K391V Datasheet
-
ECAD Model
- Share
In Stock: 883
Can ship immediately
Pricing:
- 1$3.28
- 125$1.9334
- 250$1.65721
- 625$1.47306
- 875$1.38101
- 1,250$1.28894
- 3,125$1.2429
- 6,250$1.19687
Quote It
Technical Details
- Series:TP, Anti-Vibration
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:390 µF
- Tolerance:±20%
- Voltage - Rated:80 V
- ESR (Equivalent Series Resistance):100mOhm @ 100kHz
- Lifetime @ Temp.:3000 Hrs @ 125°C
- Operating Temperature:-55°C ~ 125°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive, High Temperature Reflow
- Ripple Current @ Low Frequency:1.425 A @ 120 Hz
- Ripple Current @ High Frequency:1.9 A @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.669" (17.00mm)
- Surface Mount Land Size:0.669" L x 0.669" W (17.00mm x 17.00mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
