EKYB250ELL682ML40S
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 6800UF 20% 25V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EKYB250ELL682ML40S Datasheet
-
ECAD Model
- Share
In Stock: 564
Can ship immediately
Pricing:
- 1$3.38
- 10$2.7319
- 100$2.08624
- 500$1.58952
- 1,000$1.39082
- 2,500$1.34114
- 5,000$1.29147
Quote It
Technical Details
- Series:KYB
- Package:Bulk
- Part Status:Active
- Capacitance:6800 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:3.587 A @ 120 Hz
- Ripple Current @ High Frequency:4.22 A @ 100 kHz
- Impedance:13 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):1.634" (41.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
