UKT1H682MRD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- Description50V 6800UF 20% AUDIO-LEADED
- CategoryAluminum Electrolytic Capacitors
- Datasheet UKT1H682MRD Datasheet
-
ECAD Model
- Share
In Stock: 188
Can ship immediately
Pricing:
- 1$4.68
- 10$4.20823
- 100$3.17966
- 500$2.61855
- 1,000$2.43151
- 2,500$2.38475
Quote It
Technical Details
- Series:UKT
- Package:Bulk
- Part Status:Active
- Capacitance:6800 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:Audio
- Ripple Current @ Low Frequency:2.5 A @ 120 Hz
- Ripple Current @ High Frequency:2.875 A @ 10 kHz
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:0.866" Dia (22.00mm)
- Height - Seated (Max):2.028" (51.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
