ALC70A153CD040
KEMET
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 15000UF 20% 40V RADIAL
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 153
Can ship immediately
Pricing:
- 1$6.55
- 10$5.82492
- 100$4.65994
- 500$4.00464
- 1,000$3.71339
- 2,500$3.64058
Quote It
Technical Details
- Series:ALC70
- Package:Bulk
- Part Status:Active
- Capacitance:15000 µF
- Tolerance:±20%
- Voltage - Rated:40 V
- ESR (Equivalent Series Resistance):48mOhm @ 100Hz
- Lifetime @ Temp.:13000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:6.41 A @ 100 Hz
- Ripple Current @ High Frequency:8.34 A @ 10 kHz
- Impedance:40 mOhms
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:1.181" Dia (30.00mm)
- Height - Seated (Max):1.654" (42.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
