ALS31A472NP400
KEMET
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 4700UF 20% 400V SCREW
- CategoryAluminum Electrolytic Capacitors
- Datasheet ALS31A472NP400 Datasheet
-
ECAD Model
- Share
In Stock: 221
Can ship immediately
Pricing:
- 1$68.09
- 10$63.83241
- 100$57.87472
Quote It
Technical Details
- Series:ALS31
- Package:Bulk
- Part Status:Active
- Capacitance:4700 µF
- Tolerance:±20%
- Voltage - Rated:400 V
- ESR (Equivalent Series Resistance):33mOhm @ 100Hz
- Lifetime @ Temp.:20000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:18 A @ 100 Hz
- Ripple Current @ High Frequency:26 A @ 10 kHz
- Impedance:24 mOhms
- Lead Spacing:1.252" (31.80mm)
- Size / Dimension:3.032" Dia (77.00mm)
- Height - Seated (Max):5.827" (148.00mm)
- Surface Mount Land Size:-
- Mounting Type:Chassis Mount
- Package / Case:Radial, Can - Screw Terminals
