UHE1H151MPD1TD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 150UF 20% 50V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UHE1H151MPD1TD Datasheet
-
ECAD Model
- Share
In Stock: 1,551
Can ship immediately
Pricing:
- 1$0.54
- 500$0.17089
- 1,000$0.14526
- 2,500$0.13672
- 5,000$0.12817
- 12,500$0.11749
- 25,000$0.11621
Quote It
Technical Details
- Series:UHE
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:150 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:7000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:532 mA @ 120 Hz
- Ripple Current @ High Frequency:760 mA @ 100 kHz
- Impedance:120 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.551" (14.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
