ULD2G1R2MPD1TD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1.2UF 20% 400V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet ULD2G1R2MPD1TD Datasheet
-
ECAD Model
- Share
In Stock: 1,197
Can ship immediately
Pricing:
- 1$0.76
- 1,000$0.20159
- 2,000$0.18973
- 5,000$0.17787
- 10,000$0.16601
- 25,000$0.16009
- 50,000$0.15416
Quote It
Technical Details
- Series:ULD
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:1.2 µF
- Tolerance:±20%
- Voltage - Rated:400 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:12000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:28 mA @ 120 Hz
- Ripple Current @ High Frequency:56 mA @ 100 kHz
- Impedance:-
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.433" (11.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
