USR1HR47MDD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 0.47UF 20% 50V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet USR1HR47MDD Datasheet
-
ECAD Model
- Share
In Stock: 391
Can ship immediately
Pricing:
- 1$0.26
- 10$0.17635
- 100$0.0893
- 500$0.06113
- 1,000$0.05408
- 2,500$0.05173
- 5,000$0.04703
Quote It
Technical Details
- Series:USR
- Package:Bulk
- Part Status:Not For New Designs
- Capacitance:0.47 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:5 mA @ 120 Hz
- Ripple Current @ High Frequency:7.5 mA @ 10 kHz
- Impedance:-
- Lead Spacing:0.059" (1.50mm)
- Size / Dimension:0.157" Dia (4.00mm)
- Height - Seated (Max):0.315" (8.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
