EMHJ350ADA101MHA0G
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 100UF 20% 35V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet EMHJ350ADA101MHA0G Datasheet
-
ECAD Model
- Share
In Stock: 1,032
Can ship immediately
Pricing:
- 1$1.63
- 1,000$0.39452
- 2,000$0.36907
- 5,000$0.34998
- 10,000$0.34617
Quote It
Technical Details
- Series:Alchip™- MHJ
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:100 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):150mOhm @ 100kHz
- Lifetime @ Temp.:2000 Hrs @ 125°C
- Operating Temperature:-40°C ~ 125°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:140 mA @ 120 Hz
- Ripple Current @ High Frequency:350 mA @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.406" (10.30mm)
- Surface Mount Land Size:0.327" L x 0.327" W (8.30mm x 8.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
