EKYB160ELL821MH20D
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 820UF 20% 16V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EKYB160ELL821MH20D Datasheet
-
ECAD Model
- Share
In Stock: 634
Can ship immediately
Pricing:
- 1$0.74
- 10$0.52458
- 100$0.3455
- 500$0.2559
- 1,000$0.21753
- 2,500$0.20473
- 5,000$0.19194
Quote It
Technical Details
- Series:KYB
- Package:Bulk
- Part Status:Active
- Capacitance:820 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:726 mA @ 120 Hz
- Ripple Current @ High Frequency:1.21 A @ 100 kHz
- Impedance:60 mOhms
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.846" (21.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
