UBT1H101MPD8
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 100UF 20% 50V THRU HOLE
- CategoryAluminum Electrolytic Capacitors
- Datasheet UBT1H101MPD8 Datasheet
-
ECAD Model
- Share
In Stock: 812
Can ship immediately
Pricing:
- 1$0.75
- 10$0.54886
- 100$0.37614
- 500$0.29775
- 1,000$0.25073
- 2,500$0.23505
- 5,000$0.21939
Quote It
Technical Details
- Series:UBT
- Package:Bulk
- Part Status:Active
- Capacitance:100 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 125°C
- Operating Temperature:-40°C ~ 125°C
- Polarization:Polar
- Ratings:-
- Applications:Automotive
- Ripple Current @ Low Frequency:277.5 mA @ 120 Hz
- Ripple Current @ High Frequency:555 mA @ 100 kHz
- Impedance:180 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.571" (14.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
