UUG1E102MNQ1MS
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1000UF 20% 25V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UUG1E102MNQ1MS Datasheet
-
ECAD Model
- Share
In Stock: 567
Can ship immediately
Pricing:
- 1$1.32
- 150$0.7128
- 300$0.6336
- 750$0.50688
- 1,050$0.4752
- 3,750$0.44352
- 7,500$0.43084
Quote It
Technical Details
- Series:UUG
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:1000 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:820 mA @ 120 Hz
- Ripple Current @ High Frequency:943 mA @ 10 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):0.669" (17.00mm)
- Surface Mount Land Size:0.535" L x 0.535" W (13.60mm x 13.60mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
