ELXZ250ELL331MH15D
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 330UF 20% 25V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet ELXZ250ELL331MH15D Datasheet
-
ECAD Model
- Share
In Stock: 486
Can ship immediately
Pricing:
- 1$0.79
- 10$0.56177
- 100$0.36972
- 500$0.27387
- 1,000$0.23279
- 2,500$0.21909
- 5,000$0.2054
Quote It
Technical Details
- Series:LXZ
- Package:Bulk
- Part Status:Active
- Capacitance:330 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:365 mA @ 120 Hz
- Ripple Current @ High Frequency:730 mA @ 100 kHz
- Impedance:90 mOhms
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.591" (15.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
