UCA2G100MPD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 10UF 20% 400V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UCA2G100MPD Datasheet
-
ECAD Model
- Share
In Stock: 431
Can ship immediately
Pricing:
- 1$0.81
- 10$0.59552
- 100$0.4082
- 500$0.3232
- 1,000$0.27216
- 2,500$0.25515
- 5,000$0.23814
Quote It
Technical Details
- Series:UCA
- Package:Bulk
- Part Status:Active
- Capacitance:10 µF
- Tolerance:±20%
- Voltage - Rated:400 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-25°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:140 mA @ 120 Hz
- Ripple Current @ High Frequency:280 mA @ 100 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.846" (21.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
