EEU-FR0J122
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1200UF 20% 6.3V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-FR0J122 Datasheet
-
ECAD Model
- Share
In Stock: 266
Can ship immediately
Pricing:
- 1$0.85
- 10$0.5973
- 100$0.39353
- 500$0.29153
- 1,000$0.2478
- 2,500$0.23323
- 5,000$0.21865
Quote It
Technical Details
- Series:FR
- Package:Bulk
- Part Status:Active
- Capacitance:1200 µF
- Tolerance:±20%
- Voltage - Rated:6.3 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:6000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.032 A @ 120 Hz
- Ripple Current @ High Frequency:1.24 A @ 100 kHz
- Impedance:43 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.551" (14.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
