UPM2D4R7MPD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 4.7UF 20% 200V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPM2D4R7MPD Datasheet
-
ECAD Model
- Share
In Stock: 962
Can ship immediately
Pricing:
- 1$0.88
- 10$0.64571
- 100$0.44298
- 500$0.3507
- 1,000$0.29531
- 2,500$0.27685
- 5,000$0.2584
Quote It
Technical Details
- Series:UPM
- Package:Bulk
- Part Status:Active
- Capacitance:4.7 µF
- Tolerance:±20%
- Voltage - Rated:200 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:60 mA @ 120 Hz
- Ripple Current @ High Frequency:96 mA @ 10 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.669" (17.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
