UPW1A152MPD6
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1500UF 20% 10V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPW1A152MPD6 Datasheet
-
ECAD Model
- Share
In Stock: 500
Can ship immediately
Pricing:
- 1$0.89
- 10$0.65486
- 100$0.44907
- 500$0.35554
- 1,000$0.29939
- 2,500$0.28068
- 5,000$0.26197
Quote It
Technical Details
- Series:UPW
- Package:Bulk
- Part Status:Active
- Capacitance:1500 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.224 A @ 120 Hz
- Ripple Current @ High Frequency:1.44 A @ 100 kHz
- Impedance:45 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.984" (25.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
