EGXL160ELL221MJC5S
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 220UF 20% 16V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EGXL160ELL221MJC5S Datasheet
-
ECAD Model
- Share
In Stock: 1,131
Can ship immediately
Pricing:
- 1$0.91
- 10$0.64711
- 100$0.42626
- 500$0.31576
- 1,000$0.26839
- 2,500$0.2526
- 5,000$0.23682
Quote It
Technical Details
- Series:GXL
- Package:Bulk
- Part Status:Active
- Capacitance:220 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 125°C
- Operating Temperature:-40°C ~ 125°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:400 mA @ 120 Hz
- Ripple Current @ High Frequency:800 mA @ 100 kHz
- Impedance:170 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.551" (14.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
