UPJ1K101MHD6
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 100UF 20% 80V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPJ1K101MHD6 Datasheet
-
ECAD Model
- Share
In Stock: 805
Can ship immediately
Pricing:
- 1$0.92
- 10$0.67965
- 100$0.46621
- 500$0.36906
- 1,000$0.31077
- 2,500$0.29136
- 5,000$0.27193
Quote It
Technical Details
- Series:UPJ
- Package:Bulk
- Part Status:Active
- Capacitance:100 µF
- Tolerance:±20%
- Voltage - Rated:80 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:308 mA @ 120 Hz
- Ripple Current @ High Frequency:466 mA @ 10 kHz
- Impedance:230 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):0.650" (16.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
