EEU-FC2A221B
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 220UF 20% 100V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-FC2A221B Datasheet
-
ECAD Model
- Share
In Stock: 553
Can ship immediately
Pricing:
- 1$1.78
- 250$0.85335
- 500$0.72536
- 750$0.68268
- 1,250$0.64001
- 2,500$0.59735
- 6,250$0.57601
- 12,500$0.54401
Quote It
Technical Details
- Series:FC
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:220 µF
- Tolerance:±20%
- Voltage - Rated:100 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:760.5 mA @ 120 Hz
- Ripple Current @ High Frequency:1.17 A @ 100 kHz
- Impedance:89 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):1.063" (27.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
