EEU-FC0J272L
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 2700UF 20% 6.3V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-FC0J272L Datasheet
-
ECAD Model
- Share
In Stock: 352
Can ship immediately
Pricing:
- 1$0.97
- 10$0.73905
- 100$0.52888
- 500$0.40948
- 1,000$0.35261
- 2,500$0.32986
- 5,000$0.3128
Quote It
Technical Details
- Series:FC
- Package:Bulk
- Part Status:Active
- Capacitance:2700 µF
- Tolerance:±20%
- Voltage - Rated:6.3 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:1.543 A @ 120 Hz
- Ripple Current @ High Frequency:1.815 A @ 100 kHz
- Impedance:35 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):1.181" (30.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
