63ZLJ180M10X16
Rubycon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 180UF 20% 63V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet 63ZLJ180M10X16 Datasheet
-
ECAD Model
- Share
In Stock: 847
Can ship immediately
Pricing:
- 1$1.04
- 10$0.79271
- 100$0.56692
- 500$0.43888
- 1,000$0.37792
- 2,500$0.35354
- 5,000$0.33526
Quote It
Technical Details
- Series:ZLJ
- Package:Bulk
- Part Status:Active
- Capacitance:180 µF
- Tolerance:±20%
- Voltage - Rated:63 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:600 mA @ 120 Hz
- Ripple Current @ High Frequency:1.2 A @ 100 kHz
- Impedance:76 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.689" (17.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
