UHW1J681MHD6TN
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 680UF 20% 63V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UHW1J681MHD6TN Datasheet
-
ECAD Model
- Share
In Stock: 469
Can ship immediately
Pricing:
- 1$2.08
- 250$0.9994
- 500$0.88836
- 750$0.83284
- 1,250$0.77731
- 2,500$0.74955
- 6,250$0.72179
- 12,500$0.69403
Quote It
Technical Details
- Series:UHW
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:680 µF
- Tolerance:±20%
- Voltage - Rated:63 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.428 A @ 120 Hz
- Ripple Current @ High Frequency:2.38 A @ 100 kHz
- Impedance:50 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
