EEE-HD1E222AM
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 2200UF 20% 25V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEE-HD1E222AM Datasheet
-
ECAD Model
- Share
In Stock: 682
Can ship immediately
Pricing:
- 1$2.17
- 125$1.21964
- 250$1.04537
- 625$0.92922
- 875$0.87116
- 1,250$0.81307
- 3,125$0.78403
- 6,250$0.75499
- 12,500$0.72595
Quote It
Technical Details
- Series:HD
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:2200 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive, High Temperature Reflow
- Ripple Current @ Low Frequency:1.2 A @ 120 Hz
- Ripple Current @ High Frequency:1.5 A @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.669" (17.00mm)
- Surface Mount Land Size:0.669" L x 0.669" W (17.00mm x 17.00mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
