UVY1C332MHD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 3300UF 20% 16V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UVY1C332MHD Datasheet
-
ECAD Model
- Share
In Stock: 360
Can ship immediately
Pricing:
- 1$1.35
- 10$1.06962
- 100$0.8025
- 500$0.60633
- 1,000$0.53498
- 2,500$0.49931
- 5,000$0.48506
Quote It
Technical Details
- Series:UVY
- Package:Bulk
- Part Status:Active
- Capacitance:3300 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.17 A @ 120 Hz
- Ripple Current @ High Frequency:1.3455 A @ 10 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):1.063" (27.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
