UHE1V152MHD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1500UF 20% 35V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UHE1V152MHD Datasheet
-
ECAD Model
- Share
In Stock: 582
Can ship immediately
Pricing:
- 1$1.41
- 10$1.11195
- 100$0.83362
- 500$0.62984
- 1,000$0.55575
- 2,500$0.51869
- 5,000$0.50017
Quote It
Technical Details
- Series:UHE
- Package:Bulk
- Part Status:Active
- Capacitance:1500 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:2.304 A @ 120 Hz
- Ripple Current @ High Frequency:2.88 A @ 100 kHz
- Impedance:20 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):1.398" (35.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
